96334066

Filter

890-915&935-960MHz Add To Favorites
Area:
Amount：

+ -

In Stock：9999
Buy Add To Cart
Downloads(only for member) Register Shopping Process

Support Hotline:

Related Products


Specifications Outline Drawing

Product Classification

Product TypeFilter


General Specifications

Color

Light Gray(Customizable)
Modularity

1-Single
Mounting

Wall Mounted
RF Connector Interface

4.3-10 Female


Electrical Specifications

Frequency Range, Mhz

890-915&935-960MHz
Insertion Loss, typical, dB

≤0.7@890-891.7MHz,

≤0.5@891.7-915MHz

≤1.5@935-936.5MHz,

≤1.2@936.5-937MHz,

≤0.8@937-947.5MHz,

≤0.35@947.5-960MHz

Return Loss (dB)

≤-18/1.3:1
Rejection(dB)

≥50@869-884MHz,

≥25@930-934MHz

Input Power, RMS, maximum, W

80@936-937MHz,

100@937-960MHz

3rd Order PIM, typical, dBc

≤-155

Impedance (Ω)

50


Dimensions

Dimensions(excluding connectors and mounting bracket)(mm)

348x292x136 mm


Environmental Specifications

Operational Temperature

0 to 65°C
Operational Humidity

≤95%
Ingress Protection Class

IP65(Indoor and Outdoor)
